[ixpmanager] Graph MRTG Sub Interface IXP Manager

[Hersan Yudhaprana]

Hi Nick,

Where drop-down sub interface will appear? im already try your advice
but sub interface still not there.


--
Regards,

Hersan Yudhaprana Firman
Internet Network Engineer
---------------------------------------------------------------
PT. Supra Primatama Nusantara (Biznet)
MidPlaza 2, 8th Floor. Jl. Jend. Sudirman Kav 10-11.
Jakarta 10220 - Indonesia.
Phone: +62-21-57998888 Fax: +62-21-5700580
Call Biznet: 1500988 Web: www.biznetnetworks.com.
---------------------------------------------------------------
Biznet is an integrated digital infrastructure company in Indonesia, providing Internet, Data Center, Cloud Computing and IPTV services. We have a strong commitment to build modern infrastructure to reduce digital gap between Indonesia and other developing countries. Biznet has been operating thousands of KM state of the art Fiber Optic Network and the largest data center in Indonesia since 2000.

Biznet Internet + IPTV services are available in 110+ cities in Java, Bali, Sumatra, Batam, Kalimantan and Sulawesi islands, please visit http://www.biznetnetworks.com/fiber for complete city list.

Biznet GIO Cloud is The Newest Generation of Cloud Computing Service, please visit www.biznetgiocloud.com for details.

This message including any attachments, is intended only for the person authorized to receive it, therefore the recipient must maintain the confidentiality of this information in accordance with the provisions and / or policies of PT. Supra Primatama Nusantara (Biznet). If you are not the person authorized to receive this message then you must remove from your system and destroy all material or information derived from this information together with all copies and immediately notify the sender. Please note also that any disclosure, copy, distribute and / or other actions based on this information is prohibited and may violate the rule of law.

On 04/09/2020 16:55, Nick Hilliard (INEX) wrote:
> Hersan Yudhaprana wrote on 04/09/2020 10:30:
>> I have case our customer using NNI Port to our router, with 2
>> different services. How i can graph sub interface at ixp manager? By
>> default only port and LAG appear.
>
> Hi Hersan
>
> If the customer is connected to a subinterface with a name (e.g.
> GigabitEthernet1/10.100), and if IXP Manager is correctly configured
> with switch interface polling, then this interface name should already
> appear in the list of ports on the switch.  If it's there, you'll need
> to change the port type from "Unknown / Unset" to "Peering", and once
> you do this, it will appear in the drop-down list of ports available
> for customers.
>
> Nick
>
