Hi support
I am now to get ixp manager to my lab to check the full performance before certified at our IXP, I have now problem at run Birdeye v 1.22 with Birdv2.0.7, but let me inform you about what did
I have two VM connected to gather with details:
1- VM1: have a dual homed have IXP MANAGER and MRTG (185.153.160.202 access with switch and 192.168.1.202 access from outside)
2- VM2: have a dual homed have Birdv2 and Birdeye (185.153.160.203 access with member for BGP peering and 192.168.1.203 to access from outside and to connect with ixp manager)
· The birdv2 installed and every member at the lab connected without any problem and exchange the prefixes between us .
· I did procedure at the link for birdeye https://github.com/inex/birdseye/ , but I prefom the .env like this “cp .env.example birdseye-rs1-lan1-ipv4.env “ despite of there is single BIRD daemon
· The part of “ Vagrant / Development ” is neglected completely where I think not need at my case .
· Installed lighhtpd web server as well as link page https://www.osradar.com/install-lighttpd-ubuntu-20-04/
· The output from IXP MANAGER like this :
mysql> SELECT * FROM routers WHERE id = 1\G
*************************** 1. row ***************************
id: 1
vlan_id: 1
handle: rs1-lan1-ipv4
protocol: 4
type: 1
name: IXP Route Server #1
shortname: RS1 - VLAN10 - IPv4
router_id: 185.153.160.203
peering_ip: 185.153.160.203
asn: 61274
software: 6
software_version: 2.0.7
operating_system: Ubunitu Linux
operating_system_version: 20.04
mgmt_host: 192.168.1.204
api: http://192.168.1.203/api
api_type: 1
lg_access: 0
quarantine: 0
bgp_lc: 1
rpki: 1
rfc1997_passthru: 0
template: api/v4/router/server/bird2/standard
skip_md5: 1
last_updated: 2020-09-10 03:16:49
1 row in set (0.02 sec)
root at ixpmanager:/srv/ixpmanager# curl -v http://192.168.1.203/api/status
* Trying 192.168.1.203:80...
* TCP_NODELAY set
* Connected to 192.168.1.203 (192.168.1.203) port 80 (#0)
> GET /api/statu HTTP/1.1
> Host: 192.168.1.203
> User-Agent: curl/7.68.0
> Accept: */*
>
* Empty reply from server
* Connection #0 to host 192.168.1.203 left intact
curl: (52) Empty reply from server
root at ixpmanager:/srv/ixpmanager#
root at ixpmanager:/srv/ixpmanager# tail -f /srv/ixpmanager/storage/logs/laravel.log
#59 /srv/ixpmanager/vendor/laravel/framework/src/Illuminate/Pipeline/Pipeline.php(171): Illuminate\\Foundation\\Http\\Middleware\\ValidatePostSize->handle()
#60 /srv/ixpmanager/vendor/laravel/framework/src/Illuminate/Foundation/Http/Middleware/CheckForMaintenanceMode.php(63): Illuminate\\Pipeline\\Pipeline->Illuminate\\Pipeline\\{closure}()
#61 /srv/ixpmanager/vendor/laravel/framework/src/Illuminate/Pipeline/Pipeline.php(171): Illuminate\\Foundation\\Http\\Middleware\\CheckForMaintenanceMode->handle()
#62 /srv/ixpmanager/vendor/laravel/framework/src/Illuminate/Pipeline/Pipeline.php(105): Illuminate\\Pipeline\\Pipeline->Illuminate\\Pipeline\\{closure}()
#63 /srv/ixpmanager/vendor/laravel/framework/src/Illuminate/Foundation/Http/Kernel.php(145): Illuminate\\Pipeline\\Pipeline->then()
#64 /srv/ixpmanager/vendor/laravel/framework/src/Illuminate/Foundation/Http/Kernel.php(110): Illuminate\\Foundation\\Http\\Kernel->sendRequestThroughRouter()
#65 /srv/ixpmanager/public/index.php(85): Illuminate\\Foundation\\Http\\Kernel->handle()
#66 {main}
"}
[2020-09-10 03:16:47] development.INFO: Generated router configuration for rs1-lan1-ipv4 and used 10879368 bytes (12582912 real) of memory.
· The output from Birdeye like this :
root at bird:/srv/birdseye/bin# cat /srv/birdseye/version.php
<?php
$_ENV['BIRDSEYE_API_VERSION'] = '1.2.2';
root at bird:/srv/birdseye/bin#
root at bird:/srv/birdseye/bin# ls -la /var/run/bird
total 0
drwxrwxr-x 2 bird bird 80 Sep 10 00:16 .
drwxr-xr-x 33 root root 1060 Sep 9 23:59 ..
srw-rw---- 1 bird bird 0 Sep 9 23:53 bird.ctl
srw-rw---- 1 root root 0 Sep 10 00:16 rs1-lan1-ipv4.ctl
root at bird:/srv/birdseye/bin#
root at bird:/srv/birdseye/bin# ls -la /srv/birdseye/*env
-rw-r--r-- 1 root root 2972 Sep 8 19:23 /srv/birdseye/birdseye-rs1-lan1-ipv4.env
root at bird:/srv/birdseye/bin#
root at bird:/srv/birdseye/bin# cat /srv/birdseye/*env | egrep -v '(^#)|(^\s*$)'
BIRDC="/usr/bin/sudo /srv/birdseye/bin/birdc -2 -s /var/run/bird/rs1-lan1-ipv4.ctl"
CACHE_DRIVER=file
LOOKING_GLASS_ENABLED=false
root at bird:/srv/birdseye/bin#
root at bird:/srv/birdseye/bin# /usr/sbin/birdc -s /var/run/bird/rs1-lan1-ipv4.ctl show status
BIRD 2.0.7 ready.
BIRD 2.0.7
Router ID is 185.153.160.203
Current server time is 2020-09-10 02:16:07
Last reboot on 2020-09-10 00:16:49
Last reconfiguration on 2020-09-10 00:16:49
Daemon is up and running
root at bird:/srv/birdseye/bin#
root at bird:~# netstat -lpn | grep lighttpd
tcp 0 0 0.0.0.0:80 0.0.0.0:* LISTEN 979/lighttpd
root at bird:~# netstat -lpn | grep php
tcp 0 0 127.0.0.1:9000 0.0.0.0:* LISTEN 866/php-fpm: master
root at bird:~# cat /etc/lighttpd/lighttpd.conf
server.modules = (
"mod_indexfile",
"mod_access",
"mod_alias",
"mod_compress",
"mod_redirect",
"mod_rewrite",
)
#server.document-root = "/var/www/html"
server.document-root = "/srv/birdseye/public"
server.upload-dirs = ( "/var/cache/lighttpd/uploads" )
server.errorlog = "/var/log/lighttpd/error.log"
#server.pid-file = "/run/lighttpd.pid"
server.pid-file = "/var/run/lighttpd.pid"
server.username = "www-data"
server.groupname = "www-data"
server.port = 80
# strict parsing and normalization of URL for consistency and security
# https://redmine.lighttpd.net/projects/lighttpd/wiki/Server_http-parseoptsDetails
# (might need to explicitly set "url-path-2f-decode" = "disable"
# if a specific application is encoding URLs inside url-path)
server.http-parseopts = (
"header-strict" => "enable",# default
"host-strict" => "enable",# default
"host-normalize" => "enable",# default
"url-normalize-unreserved"=> "enable",# recommended highly
"url-normalize-required" => "enable",# recommended
"url-ctrls-reject" => "enable",# recommended
"url-path-2f-decode" => "enable",# recommended highly (unless breaks app)
#"url-path-2f-reject" => "enable",
"url-path-dotseg-remove" => "enable",# recommended highly (unless breaks app)
#"url-path-dotseg-reject" => "enable",
#"url-query-20-plus" => "enable",# consistency in query string
)
#index-file.names = ( "index.php", "index.html" )
index-file.names = ( "index.php", "index.html", "index.lighttpd.html" )
url.access-deny = ( "~", ".inc" )
static-file.exclude-extensions = ( ".php", ".pl", ".fcgi" )
compress.cache-dir = "/var/cache/lighttpd/compress/"
compress.filetype = ( "application/javascript", "text/css", "text/html", "text/plain" )
# default listening port for IPv6 falls back to the IPv4 port
## Use ipv6 if available
#include_shell "/usr/share/lighttpd/use-ipv6.pl " + server.port
include_shell "/usr/share/lighttpd/create-mime.conf.pl"
include_shell "/usr/share/lighttpd/include-conf-enabled.pl"
#include "/etc/lighttpd/conf-enabled/*.conf"
#server.compat-module-load = "disable"
server.modules += (
"mod_compress",
"mod_dirlisting",
"mod_staticfile",
)
url.redirect = ()
url.rewrite-once = (
"^/(css|img|js|fonts)/.*\.(jpg|jpeg|gif|png|swf|avi|mpg|mpeg|mp3|flv|ico|css|js|woff|ttf)$" => "$0",
"^/(favicon\.ico|robots\.txt|sitemap\.xml)$" => "$0",
"^/[^\?]*(\?.*)?$" => "index.php/$1"
)
root at bird:~#
I sent to you laravel.log file , if you need,,,,,,
Where is the Problem ,,,,,,
I am waiting you relpy ,,,,
Thanks in advanced ,,,,,
--
Eng.Basil Elbalaawi
QOS Department - Complaints Unit
bbalaawi at mtit.gov.ps
SecdepBasil at yahoo.com
Jawwal 0599409108
Wataniay 0562504972
