[ixpmanager] Allow a peer with the same AS number as the route-servers

[Barry O'Donovan (INEX)]

Hi Tom,

An ASN, among other things, defines a specific routing policy, and in
the case of route servers, that’s multilateral peering as defined by
rfc7947.

The route server configuration explicitly prevents the same peer ASN
peering with them. This is very much on purpose.

In your case, there’d be the additional issue of your routes potentially
having no ASN or, inexplicitly and unexpectedly, having the route server
ASN suddenly appear on your members' routing tables. Remember - route
server ASNs are transparent.

When I last looked, ASNs from LACNIC had a once-off allocation fee. The
best thing to do here is to register a new ASN for the IXP’s own
management systems. This is what most IXPs do, including INEX.

  - Barry



------ Original Message ------
>From "Tom Lima via ixpmanager" <ixpmanager at inex.ie>
To ixpmanager at inex.ie
Cc "Tom Lima" <tom at infnoc.net>
Date 05/04/2025 06:41:35
Subject [ixpmanager] Allow a peer with the same AS number as the
route-servers

>Hello everyone,
>
>
>
>I would like to know how I can modify/add so I can allow a peer with
>the same ASN as the route server ASNs.
>
>
>
>Reason is our IXP doesn't have separate ASNs for management and
>Route-Servers, and I need to announce the ASN other prefixes that
>provides a few tools to the users (Looking Glass, Graphs, etc).
>
>
>
>We do have a /23 prefix, which a /24 is allocated to the IXP Exchange
>VLAN, and the other /24 is for management purposes. We do need to
>announce that /24 management address using the same ASN that run the
>route-server service.
>
>
>
>I tried adding a Internal User and Peer with the AS, but
>IXPManager/Bird doesn't create the BGP sessions for that peer.
>
>
>
>Let me know what I need to edit to allow this behavior.
>
>
>
>Best regards
>
>--
>
>
>
>Tom Lima
>Network Engineeer Consultant
>
>tom at infnoc.net
>WhatsApp: +55 (41) 2018-2165
>
><https://www.facebook.com/Infnoc.net>
><https://www.linkedin.com/company/infnoc/>
><https://www.instagram.com/infnoc/>
>
>www.infnoc.net <https://www.infnoc.net>
>--------------------------------------------------------------------------------
>Essa mensagem pode conter conteúdo confidencial, não copie ou divulgue
>o conteúdo.
>
>Este mensaje puede contener contenido confidencial, no copie ni
>divulgue el contenido.
>
>This message may contain confidential content, do not copy or disclose
>the content.
>
